Slimview
../include/upload/uploadImages/images/20140617174211.jpg

 TECHNICAL FEATURES
• CPU ARM7TDMI-S core
• Power supply: 8 – 32 Vdc, protected against reverse polarity and load-dump
• Display 7” 16/9 transmissive TFT LCD WVGA 800x480 pixels, 24 bit color
• Capacitive touchscreen
• Orientation: Landscape or portrait
• Backlight: LED 450cd/m²
• 2 Digital INPUT 0 - Vbatt
• 4 Analog INPUT current 4-20mA o voltage 0-Vbatt configurable by SW
• 2 Digital INPUT 0 – Vbatt or digital OUTPUT 2A (HSD) configurable by SW
• 1 CANBUS port
• 1 USB port
• Connection made by a cable and Tyco SUPERSEALconnector
• Operating Temperature -20°C + 70°C
• Protection degree IP67
• ABS plastic enclouser (black)
• Bootloader via CANBUS or USB
• Programmable with C language or graphical SW eDash3K powered by AMA
